Lub peev xwm ntau npaum li cas yuav tsum muaj Block Making Machine?

Xaiv qhov muaj peev xwm tsim tau raug rau lub tshuab ua thaiv tsis yog tsuas yog hais txog tus lej xwb; nws ncaj qha txiav txim siab koj qhov project ncua sij hawm, cov nqi ua haujlwm, thiab cov txiaj ntsig ntev. Tom qab ob xyoos dhau los hauv kev ua haujlwm ntawm cov tshuab hnyav, peb lub Hoobkas tau kawm tias muaj peev xwm tsis sib haum feem ntau ua rau cov khoom siv tsis siv neeg lossis tsis muaj sijhawm. Txawm hais tias koj tab tom tsim cov blocks hollow, pavers, lossis kerbstones, kev nkag siab txog cov khoom tsim tawm uas haum rau koj lub voj voog xav tau yog thawj kauj ruam mus rau kev lag luam khoom lag luam ruaj khov.

Hauv phau ntawv qhia no, peb pab neeg ntawm Quangong Machinery Co., Ltd. rhuav tshem cov kev tshawb fawb tom qab kev npaj peev txheej. Peb yuav tshawb xyuas seb yam xwm txheej zoo li cas pwm tsim, kho tshuab, thiab lub sijhawm hloov pauv cuam tshuam rau lub ntiaj teb cov khoom tsim tawm. Thaum kawg ntawm tsab xov xwm no, koj yuav paub raws nraim li cas los ntsuas qhov xav tau ntau lawm ntim ib teev thiab ua haujlwm. Peb tseem yuav nthuav qhia cov ncauj lus kom ntxaws technical parameters ntawmQGM Block Ua Tshuab, xyuas kom koj muaj cov ntaub ntawv xav tau los ua kom paub txog peev peev. Cia peb pab koj txhim kho koj lub vaj tsev thaiv.

Dab tsi yog Qhov Kev Txiav Txim Siab Tshaj Lij Tshaj Lij Tshaj Lij Tshaj Lij Tshaj Lij Tshaj Lij Tshaj Lij Tshaj Lij Tshaj Lij Tshaj Tawm?

Kev txiav txim siab qhov muaj peev xwm zoo suav nrog kev txheeb xyuas ntau qhov sib txawv ntawm qhov sib txawv. Peb lub Hoobkas tau teeb tsa ntau dua ib txhiab units thoob ntiaj teb, thiab peb niaj hnub pom tias cov neeg yuav khoom tau zoo xav txog tsib lub ntsiab lus tseem ceeb ua ntej xaiv lub tshuab. Tsis quav ntsej ib qho ntawm cov no feem ntau ua rau muaj peev xwm ntau dhau lossis tsis txaus rau kev xav tau ntawm kev lag luam.

• Kev txiav txim txhua hnub Volume:Xam koj qhov nruab nrab qhov xav tau txhua lub lim tiam rau blocks. Rau ib tus neeg cog lus me me xav tau 5,000 blocks ib hnub twg, qhov qis mus rau nruab nrab muaj peev xwm QGM Block Making Machine uas tsim tau 8,000 txog 12,000 blocks ib yim teev ua haujlwm txaus. Conversely, loj infrastructure tej yaam num yuav tsum tau 50,000 blocks txhua hnub xav tau siab tso zis automated kab.
• Shift Structure:Peb lub Hoobkas tsim cov tshuab uas tuaj yeem khiav ib zaug, ob npaug, lossis triple hloov. Lub tshuab ntsuas ntawm 10,000 blocks ib qho kev hloov pauv yields 20,000 blocks hauv ob chav ua haujlwm. Xav txog kev muaj peev xwm ua haujlwm thiab cov nqi hluav taws xob thaum txiav txim siab hloov cov qauv.
• Curing thiab Storage Space:Ntau lawm muaj peev xwm yog txwv los ntawm curing vaj loj. Txawm hais tias lub tshuab tsim tawm 15,000 blocks ib teev twg, cov pallets tsis txaus lossis kho cov racks yuav ua rau muaj kev tsis sib haum xeeb. Xyuas kom koj qhov thaiv ua kom muaj peev xwm ua tau raws li lub voj voog kho (feem ntau 24 txog 48 teev).
• Pwm Changeover zaus:Cov phiaj xwm sib txawv yuav tsum muaj qhov sib txawv ntawm qhov sib txawv. Yog tias koj nquag hloov ntawm hollow blocks thiab pavers, xaiv lub tshuab nrog ceev pwm clamping tshuab. Peb QGM Block Ua Tshuab txo kev hloov pauv mus rau hauv 15 feeb, khaws cia muaj peev xwm zoo.
• Raw Material Muaj:Cov tshuab muaj peev xwm siv tau ntau qhov sib xyaw thiab cov cement. Lub 1,200 thaiv ib teev ntawm lub tshuab yuav xav tau 12 tons ntawm raw khoom ib teev. Xyuas kom tseeb tias koj cov saw hlau tuaj yeem txhawb nqa cov khoom lag luam siab kawg yam tsis muaj kev cuam tshuam.

Tshaj li cov hauv paus ntsiab lus no, cov yam ntxwv kev lag luam hauv cheeb tsam ua lub luag haujlwm. Hauv kev txhim kho kev lag luam, lub peev xwm qis dua phau ntawv siv tshuab yuav txaus, thaum cov kab hluav taws xob ceev ceev tswj hwm kev lag luam paub tab. Peb qhov kev paub ntawmQuangong Machinery Co., Ltd.qhia tau hais tias lub peev xwm zoo tagnrho yog ib txwm 15 mus rau 20 feem pua ​​​​ntawm qhov siab tshaj qhov xav tau tam sim no kom haum rau kev loj hlob, tseem tsis tau siab heev uas lub tshuab khiav qis dua 60 feem pua ​​kev siv. Qhov nyiaj tshuav no tiv thaiv koj cov nyiaj rov qab los ntawm kev nqis peev thiab ua kom lub tshuab thaiv kev ua haujlwm tseem muaj txiaj ntsig tshaj nws txoj sia.

Yuav ua li cas xam qhov yuav tsum tau Block ua peev xwm rau koj qhov project?

Kev suav cov peev xwm xav tau yog plaub kauj ruam txheej txheem uas hloov cov kev xav tsis meej rau hauv cov lus qhia tshwj xeeb. Peb lub Hoobkas siv cov txheej txheem tseeb no thaum pab cov neeg siv khoom loj lawv QGM Block Making Machine. Ua raws li cov kauj ruam no kom tsis txhob poob qis lossis dhau kev nqis peev hauv cov cuab yeej tsim khoom.

Kauj ruam 1: Txiav txim siab Peak Daily Block Demand
Kwv yees qhov siab tshaj plaws ntawm cov blocks xav tau nyob rau hauv koj hnub ua haujlwm hnyav tshaj plaws. suav nrog cov npoo kev nyab xeeb rau cov khib nyiab lossis cov chaw tsis lees paub. Piv txwv li, ib txoj haujlwm vaj tse yuav tsum muaj 8,000 tus qauv hollow blocks ib hnub. Ntxiv 10 feem pua ​​​​txog = 8,800 blocks raws li lub hom phiaj tsim khoom txhua hnub.

Kauj Ruam 2: Xam Cov Sijhawm Ua Haujlwm Hauv Ib Hnub
Xav txog cov sij hawm ua haujlwm tshem tawm cov so thiab tu. Ib qho 8 teev ua haujlwm tau zoo muab 7 teev ua haujlwm tom qab ntxuav thiab teeb tsa. Rau kev hloov pauv ob zaug, 14 teev ua haujlwm. Siv qhov no: xav tau ib teev muaj peev xwm = txhua hnub xav tau / cov sij hawm tsim khoom. Rau 8,800 blocks tshaj 7 teev = 1,257 blocks ib teev yam tsawg kawg nkaus.

Kauj ruam 3: Tus account rau thaiv hom kev hloov pauv yam tseem ceeb
Cov cav tov raug ntsuas siv qhov siv thaiv (feem ntau 400x200x200mm hollow block). Ua cov blocks lossis cov pavers me me hloov cov zis. Peb QGM Block Ua Tshuab feem ntau tsim 30 feem pua ​​​​tsawg dua cov khoom thaiv piv rau cov hollow blocks vim cov khoom siv ntau dua thiab lub sijhawm vibration. Kho koj lub hom phiaj kom haum.

Kauj Ruam 4: suav nrog Downtime thiab Kho
Txawm tias cov tshuab muaj zog yuav tsum tau teem caij saib xyuas. Ib qho 5 feem pua ​​​​ntawm cov nyiaj poob haujlwm yog tus qauv. Yog li ntawd, lub peev xwm nominal xav tau = suav teev muaj peev xwm / (1 - downtime). Siv peb qhov piv txwv: 1,257 / 0.95 = 1,323 blocks ib teev twg yuav tsum tau ua raws li kev ntsuas tshuab.

Peb xav qhia kom siv lub peev xwm tsis rau yav tom ntej nthuav dav. Quangong Machinery Co., Ltd. muaj kev hloov kho modular ntawm ntau cov qauv, tso cai rau koj pib nrog lub hauv paus muaj peev xwm thiab tom qab ntawd ntxiv vibration units lossis automation. Qhov no phased mus kom ze tiv thaiv cov nyiaj ntsuab txaus thaum ua kom cov block ua tshuab loj hlob nrog koj lub lag luam. Txhawm rau kom yooj yim, peb cov kws tsim khoom muag muab cov ntawv ua haujlwm muaj peev xwm raws li koj qhov kev sib sau ua ke hauv zos thiab thaiv geometry.

Vim li cas ho txawv Block hom yuav tsum muaj peev xwm sib txawv?

Tsis yog tag nrho cov blocks raug tsim sib npaug, thiab qhov muaj peev xwm ntsuas ntawm lub tshuab thaiv kev ua haujlwm sib txawv nrog cov khoom zoo, qhov loj me, thiab qhov ntom ntom. Peb lub Hoobkas tau tsim cov pwm tshwj xeeb rau ntau tshaj 200 thaiv profile, thiab peb ua tib zoo saib xyuas tias muaj peev xwm tuaj yeem sib txawv los ntawm ib qho ntawm peb ntawm qhov yooj yim thiab nyuaj tshaj plaws block hom. Nkag siab qhov sib txawv no tiv thaiv kev poob siab tom qab kev yuav khoom.

• Txheem Hollow Blocks (400x200x200mm):Cov no yog cov qauv ntsuas rau kev ntsuas kev muaj peev xwm. Kev ua haujlwm siab QGM Block Making Machine tuaj yeem tsim 12,000 txog 15,000 units ib 8 teev ua haujlwm vim muaj kev vibration luv luv thiab ejection ceev. Lub teeb yuag aggregate ntxiv tso zis ntau ntxiv los ntawm kev txo lub sij hawm compaction.
• Khoom vaj khoom tsev Blocks:Yuav kom muaj kev vibration ntev dua thiab siab dua kom tshem tawm cov voids, cov khoom thaiv txo cov zis los ntawm 40 mus rau 50 feem pua. Lub tshuab ntsuas ntawm 10,000 hollow blocks tsuas yog tsim tau 5,500 cov khib nyiab ib zaug. Peb lub Hoobkas pom zoo xaiv lub tshuab loj dua yog tias cov khoom thaiv yog koj cov khoom tseem ceeb.
• Pavers thiab Paving Pob Zeb:Cov no muaj qhov me me tab sis yuav tsum tau ua kom tiav qhov zoo. Lub sij hawm voj voog nce vim qeeb demolding. Cia siab tias 20 mus rau 30 feem pua ​​​​tsawg muaj peev xwm piv rau hollow blocks. Txawm li cas los xij, ntau kab noj hniav pwm (txog 12 pavers ib lub voj voog) them nyiaj ib nrab.
• Interlocking Blocks thiab Kerbstones:Complex geometries xav tau meej kev co thiab kho ntev dua ntawm pallets. Lub peev xwm yuav poob mus rau 4,000 txog 6,000 units ib zaug. Quangong Machinery Co., Ltd. tau tsim tshwj xeeb hydraulic tshuab uas tswj cov zis zoo ib yam txawm tias cov duab nyuaj.
• Lub teeb yuag AAC lossis Cellular Blocks:Although not produced on conventional block machines, if using a dense concrete approach, these reduce output due to longer mixing and controlled density requirements. Nco ntsoov sab laj cov ntaub ntawv qhia txog kev siv tshuab.

Yog li ntawd, thaum ntsuam xyuas lub tshuab ua block, tsis txhob cia siab rau qhov siab tshaj plaws tshaj tawm muaj peev xwm. Hloov chaw, thov cov lus muaj peev xwm rau koj qhov tshwj xeeb thaiv qhov ntev. Peb pab neeg ntawm Quangong Machinery Co., Ltd. muab cov ntaub ntawv simulation dawb uas kho lub peev xwm raws li koj cov ntaub ntawv raw thiab hom phiaj thaiv. Qhov kev pom tseeb no ua kom paub tseeb tias QGM Block Making Machine koj yuav xa cov khoom tsim tawm txhua hnub, tshem tawm cov nqi kwv yees los ntawm koj qhov kev npaj tsim khoom.

Technical Parameters & Output Table ntawmQGM Block Ua Tshuab

Txhawm rau txiav txim siab muaj peev xwm raug, koj xav tau cov lej nyuaj. Hauv qab no peb nthuav qhia cov kev qhia tshwj xeeb rau peb tus qauv nrov ntawm QGM Block Making Machine, txhua tus tsim los rau ntau qhov sib txawv. Cov kev ntsuas no qhia txog kev sim ntiaj teb tiag hauv peb lub Hoobkas thiab tau lees paub los ntawm cov neeg siv khoom thoob ntiaj teb ntawm Zenith. Siv lub rooj no los sib piv lub voj voog lub sij hawm, qhov ntau thiab tsawg pallet, thiab thaiv cov zis ib teev.

Raws li pom saum toj no, peb QGM Block Making Machine series muaj cov kev daws teeb meem los ntawm cov lag luam me nkag mus rau kev lag luam loj. QGM-800 yog qhov zoo tagnrho rau kev pib ua haujlwm tsim 8,000 blocks ib hnub ntawm ib qho kev hloov pauv. QGM-1200, qhov nyiam ntawm cov neeg cog lus nruab nrab, xa 15,000 blocks txhua hnub. Rau cov phiaj xwm loj loj, QGM-1800 tuaj yeem tshaj 25,000 blocks ib zaug. Peb lub Hoobkas kuj customizes hydraulic siab thiab vibration zaus kom maximize tso zis rau tej aggregates. Quangong Machinery Co., Ltd. muab rau ntawm qhov chaw commissioning los xyuas kom meej lub peev xwm sib tw koj lub hom phiaj ntau lawm hauv thawj lub lim tiam ntawm kev ua haujlwm.

Tsis tas li ntawd, tag nrho peb cov tshuab muaj lub zog txuag servo motors uas tswj cov zis siab thaum txo cov nqi hluav taws xob txog li 30 feem pua ​​​​piv rau cov kab ke ib txwm muaj. Thaum xam koj ROI, nco ntsoov tias cov qauv muaj peev xwm ntau dua feem ntau muaj tus nqi qis dua ib qho thaiv. Peb cov engineers pom zoo xaiv lub tshuab uas qhov kev cia siab siv yog nyob nruab nrab ntawm 70 thiab 85 feem pua ​​​​rau kev pom zoo ntawm kev nqis peev thiab kev hloov pauv.

Xaus: Ua kom muaj peev xwm nrog lub hom phiaj ua lag luam

Kev txiav txim siab ntau npaum li cas lub peev xwm tsim lub tshuab thaiv yuav tsum muaj yog qhov kawg kev txiav txim siab ua lag luam. Tom qab tshuaj xyuas cov xwm txheej, kev suav cov txheej txheem, thiab cov lus qhia saum toj no, nws pom tseeb tias cov lus teb raug sib npaug ntawm qhov kev txiav txim tam sim no, kev loj hlob yav tom ntej, thiab cov khoom sib xyaw ua ke. Peb lub Hoobkas tau pom ntau lub tuam txhab yuav cov tshuab tsis zoo uas ua rau muaj lub cav tsis zoo lossis cov chav loj loj uas khib nyiab peev thiab hauv pem teb.

Qhov chaw qab zib rau kev ua haujlwm feem ntau yog QGM Block Ua Tshuab ntsuas ntawm 25 feem pua ​​​​ntawm koj qhov kev thov siab tshaj plaws tam sim no, nrog cov kev hloov kho tshiab. Piv txwv li, yog tias koj xav tau 10,000 blocks ib hnub twg, xaiv tus qauv muaj peev xwm ntawm 12,500 blocks ib hnub nyob rau hauv cov xwm txheej zoo sib xws. Qhov no tsis ua haujlwm raws caij nyoog spikes thiab txo cov nqi ua haujlwm dhau sijhawm. Quangong Machinery Co., Ltd. muaj kev pab tswv yim pub dawb uas peb pab neeg soj ntsuam koj lub lag luam hauv zos thiab muab cov phiaj xwm tsim khoom. Peb kuj muab cov chaw taws teeb saib xyuas uas taug qab cov khoom tawm ntawm lub sijhawm tiag tiag, pab koj kho qhov ntsuas kom muaj peev xwm zoo tshaj plaws.

Npaj los optimize koj thaiv ntau lawm? Hu rau peb lub Hoobkas hnub norau kev ntsuam xyuas tus kheej muaj peev xwm. Thov ib daim ntawv tso cai pub dawb thiab kev kos duab ntawm QGM Block Making Machine uas phim koj qhov project nplai. Peb cov engineers yuav simulate koj cov khoom siv niaj hnub siv koj cov ntaub ntawv raw hauv zos. Cia peb tsim ib qho kev daws teeb meem uas ua rau koj cov txiaj ntsig zoo tshaj plaws los ntawm hnub ib.

Cov lus nug nquag nug txog Block Ua Tshuab Muaj Peev Xwm
